Please click here to see comparison chart of the latest test data.

Bacillus atrophaeus micrographsMicrograph B atrophaeus



The 3 micrographs represent dead Bacillus atrophaeus. They show fractures and segments that were blown off of the organism while in it's vegetative state. The spores are contained inside this rod-like structure. All of the organisms, including the spores, were shown to be dead by a comparable slide that was irradiated with the same exposure and then incubated. This is the first indication that Far-UV Sterilray is breaking bonds and killing microorganisms, not just forming dimers as with the 254 nm light. This activity confirms our theory that targeting the peptide bonds of the protein molecules in microorganisms is the best and most efficient method to ensure destruction of the offending organism. The photos demonstrate the side wall ruptures and the separation of its parts caused by an explosive force. This force most likely occurs when either the peptide bond or the disulphide bond is broken by the incoming photon(s). The outer spore coat (OSC) is rich in the higher bond energy disulphide (--S-S--) bonds which may account for the segmentation fragments.
